AUTOMATED EXTERNAL DEFIBRILLATOR (AED) ZOLL PLUS
Dr. Lưu Thị Minh Trang | Trainer of the Quick First Aid Project – Saving Lives
Wellbeing Health Education Organization
The Automated External Defibrillator (AED) is a useful device in the process of providing first aid to victims of cardiac arrest. It is a medical device, but even individuals with no medical experience or knowledge can use it. Wellbeing provides genuine AED products, ensuring full warranty coverage from the manufacturer, and offers first aid training to customers. To choose the right AED model for your business or organization's needs, it's important to understand the features of each AED model. Let’s explore the ZOLL PLUS AED model in this article.
-
General Information:
Zoll Medical Corporation is a U.S.-based company that develops and distributes medical products, devices, and software to enhance the effectiveness of emergency care, first aid, and patient care. With products such as defibrillators, monitoring devices, circulatory feedback devices, and medical data management software, Zoll provides a comprehensive technology system that supports both clinical doctors and first responders.
The ZOLL PLUS AED is one of the community-serving medical devices manufactured and distributed by Zoll Medical, representing the company's newest and most advanced AED model. Additionally, Zoll also offers other AED models: ZOLL PRO, ZOLL AED 3.
Besides these products, the company also manufactures and distributes AED Trainer devices for AED training purposes.
Suspicious activity detected
2. Detailed Information about the Device:
Here are some technical specifications that may help you easily choose the right AED model for your business or organization's needs:
Device Specifications:
-
Size: 24.1 x 29.2 x 13.3 cm
-
Weight: 3.1 kg (including battery weight)
-
Power Source: 10 replaceable lithium manganese dioxide batteries, approximately 225 ± 5 shock cycles or 13 continuous hours of monitoring
-
Battery Life (standby mode): 5 years
Environment:
-
Operating Temperature: 0˚C to +50˚C
-
Humidity: 10 to 95% relative humidity
-
Vibration Resistance: MIL-STD-810F anti-vibration standard
-
Water and Dust Resistance: IP-55
Defibrillation:
-
Waveform Type: Biphasic waveform (2-phase, non-distorted)
-
Energy Levels: For adults: 120-150-200J, for children (under 8 years): 50-70-85J
-
Chest Compression Rate: 60 - 100 compressions per minute
-
Heart Rhythm Analysis Time: 12s with new battery, 13s with reduced battery after 15 cycles of 200J shocks
-
Time from Start to Shock Delivery: 22.6 seconds
3. Key Features:
3.1. Step-by-step First Aid Guidance with Both Visual and Voice Instructions:
In an emergency situation, you may panic, which can be dangerous for both you and the victim. Having a device that guides you through all the necessary steps can help you provide quick and correct first aid.
The ZOLL PLUS AED is designed to provide complete first aid steps following the guidelines of the American Heart Association (AHA), including: assessing responsiveness, calling for help, checking the airway, performing chest compressions, and rescue breathing (CPR) for the victim.
Additionally, these instructions are presented through two simultaneous channels: visual and voice guidance. The visual guidance is displayed through illustrations and an LCD screen on the device, allowing even those with hearing impairments to follow along.
3.2. Integrated Chest Compression Location Marker on the Electrode Pads:
Cardiopulmonary resuscitation (CPR) – chest compressions and rescue breathing – is a crucial action in providing first aid to a cardiac arrest victim. This action helps deliver blood and oxygen to the vital organs of the body. Performing CPR immediately significantly increases the victim's chance of survival, with each minute of delay reducing the survival rate by 7% to 10%.
To optimize the waiting time for the victim before CPR is administered, the ZOLL PLUS AED integrates a chest compression location marker along with two electrode pads. By simply placing the electrode pads in the correct position as directed, you will already have the correct spot for chest compressions, without the need to waste time determining the location on the victim’s body.
3.3. Feedback Sensor for Chest Compression Rate and Force:
CPR is an immediate action, but if performed incorrectly, it will not be effective. Effective CPR is performed with a chest compression rate of 100 to 120 compressions per minute and a chest compression depth of 5 to 6 cm. If you have never performed CPR or if you are in a state of panic, the likelihood of performing it incorrectly is very high.
The ZOLL PLUS AED integrates a sensor that detects the rate and force of chest compressions on the chest compression location marker. This sensor provides feedback to the first responder through the LCD screen on the device. The feedback messages displayed could be: Good compressions or Push harder.
4. Why You Should Choose to Buy ZOLL PLUS 3100 at Wellbeing:
Wellbeing provides your business or organization with genuine, imported devices. You will receive the following benefits:
-
Timely notifications about equipment repairs or product recalls from the manufacturer.
-
A warranty certificate from the manufacturer, ensuring that your warranty will be honored.
-
Full support and consultation from both Wellbeing and the manufacturer if you have any questions or challenges during the use of the AED device.
-
A team of 100% medically trained doctors, who are well-versed in AED device information, capable of training your business or organization in how to use the device in conjunction with other first aid skills.
